HEXA

1370 / 1906

ELECTRICAL
68
BULB REPLACEMENT PROCEDURE:
1. Remove the door Ajar lamp.
2. Remove the bulb assembly by rotating in anti-
clockwise direction.
3. Take out the bulb and replace with new one.
4. Fit the bulb assembly by rotating in clockwise
direction.
5. Fit the lamp.
8.4.11 GLOVE BOX LAMP
It consists of bulb of ratting 12V, is fitted on
the top utility bin.
REMOVAL:
1. Open the top utility bin cover.
2. Pry out the lamp assembly from the cutout.
3. Disconnect the electrical connection.
4. Take out the lamp.
REFTIMENT:
1. Connect the electrical connection.
2. Fit the lamp assembly into the cutout provided
on the top utility bin. ( Snap fitted).
BULB REPLACEMENT PROCEDURE:
1. Open the top utility bin cover.
2. Pry out the lamp assembly from the cutout.
3. Remove the bulb and replace with new one.
4. Fit the lamp assembly.
