FRONT AXLE (4X4)
19
12.Take out the stub axle assembly along with
wheel hub and brake disc.
13.Pull out the drive shaft from the carrier section
follow the same procedure at other end also.
14.Mount the drive shaft on the table and break
the toner ring using a blunt chisel or screw
driver.
CAUTION
Do the hammering on the toner ring directly to
avoid any damage to the drive shaft and rubber
boot.
FITMENT
1. Position the toner ring on the drive shaft and
with the help of toner ring pressing dolly (
Part
No. 287058903315)
install the toner ring on its
location.
For fitment follow the reverse procedure of
removal.
