HEXA

FRONT AXLE (4X4)

7. Re-position the case in press

(Part No. 2894

5890 35 19)

and remove side bearing cone

from other side in same manner.

NOTE

It is always preferred to replace side bearings

once pulled out. But one can confirm free rolling

of bearing and reuse it, if they are defect free.

8. Loosen and remove the ring gear screws and

remove the ring gear.

9. If required tap ring gear with a mallet to free it

from case.

NOTE

Discard ring gear screws and replace with new

one.

Install differential case on axle shaft.

10.Use suitable drift to remove the roll pin

retaining cross shaft.

11.Use hammer and punch as shown to remove

the cross pin from case.

remove side gears and pinion mate gears,

rotate the side gears. This will allow the pinion

mate gears to turn to opening of the case.

Remove pinion mate gears and spherical

washers behind the gears. Lift outside gears

and thrust washers.

Inspect all parts including the machined

surfaces of the case itself. Where necessary,

replace all worn parts.
