FRONT AXLE (4X4)
16
13.Support the stub axle assembly from below.
Disconnect lower wishbone ball joint using
puller
(Part No. 287058904601)
.
(For
procedure refer suspension lower wishbone
ball joint removal section.)
14.Pull out the stub axle to free it from driveshaft.
Carefully support the driveshaft.
15.Pull out the drive shaft from the carrier section
follow the same procedure at other end also.
16.Loosen and remove the mounting nut of
breather assembly.
17.Loosen and remove the rear mounting bolt of
front axle assembly.
18.Support the cross member and loosen and
remove the mounting bolts (4 from rear and 4
from front end) and lower the front axle
assembly with cross member from the vehicle.
