HEXA

BODY

N. STONE GUARD:

REMOVAL:

1. Apply the handbrake and chocks on the

wheels.

2. Loosen and remove all the mounting bolts and

remove the stone guard from the bottom

side of the vehicle.

ASSEMBLY:

For assembly follow the reverse procedure of

removal.

O. FRONT WHEEL ARC LINER:

REMOVAL:

1. Tilt the front wheel or remove the front wheel

for better access to the inner wheel arc.

2. Remove the fasteners of panel wheel arch

inner.

3. Remove all the clips and take out the liner front

wheel house outer from the vehicle.

FITMENT:

For procedure follow reverse procedure of

removal.

NOTE:

Check the plastic nut and button clips for damage

and replace the same with new one if found

damaged.
