4 DLT ENGINE
C
heck cam shaft axial play. It should be within
specified limits. Refer Figure 108
C
heck camshaft for rotation, the frictional torque
should be between 1.8 to 2.2 mkg. Refer Figure 109
I
nstall wood ruff key and cam shaft gear.Tighten cam
shaft gear mounting screw along with spacer. Refer
Figure 110.
Fig. 108
Fig. 109
Fig. 110
