495 / 1526
20
BRAKES
REAR DRUM BRAKES
1. BACK PLATE
2. LINED SHOE LEADING
3. LINED SHOETRAILING
4. SHOE HOLD DOWN PIN
5. CUPWASHER
6. SPRING
7. SHOE RETURN SPRING -W/
CYL END
8. SHOE RETURN SPRING -
ABUTMENT END
9. PUSH ROD - FEMALE
10. THERMOLIP
11. ADJUSTERNUT
12. PUSH ROD - MALE
13. HANDBRAKE LEVER
14. HAND BRAKE LEVER PIN
15. WASHER
16. CLIP
17. SPRING-HANDBRAKE
LEVER
18. PAWL LEVER
19. PAWL LEVER SPRING
20. DOWEL PIN
21. WAVEWASHER
22. PLAINWASHER
23. SPRINGWASHER
24. SET SCREWW/CYL. ASSY
25. DUST COVER
26. PISTON
27. CUP SEAL
28. SEAL RETAINER
29. SPRING
30. WHEEL CYLINDER BODY
31. BLEED SCREW
32. DUST CAP
33. GASKET
34. ADAPTOR
35. GROMMET
36. GROMMET HANDBRAKE
LEVER
Fig.15 - Exploded view of rear brake assembly.
