GEAR BOX G-76
SHIFTER FORKS
Refer fig. 52
There are three types of shifter forks.
1
st
/2
nd
shifter fork has the engaging collar at the
centre.
3
rd
/4
th
shifter fork has step collar and ribs supporting
the engaging collar. Rev./5
th
shifter fork has the
installing hole in the centre.
SHIFTER SHAFTS
Refer fig. 53
1
st
/ 2
nd
shifter shaft has two installation holes.
3
rd
/ 4
th
shifter shaft has inter locking pin in the groove
cut at the bottom.
Rev. / 5
th
shifter shaft has the installing hole near the
notch.
Fig. 53
Fig. 52
Rev / 5
th
3
rd
/ 4
th
1
st
/ 2
nd
Rev / 5
th
1
st
/ 2
nd
3
rd
/ 4
th
