ELECTRICALS
32
Fig. 39
Fig. 37
1 2 3 4 5
6 7
9
8
Operating Switches
5. Rear WindshieldWasher
6. Rear Windshield wiper
7. Fuel flap opening
8.
Headlamp leveling switch
9. Analog clock
1.
Rear fog lamp
2.
Front fog lamp
3.
Rear Windshield &
Outside Mirror Demister
4. HazardWarning
Fig. 38
15J. FACIA SWITCHES
(Fig. 37 & 39)
Function
Functions of different facia switches are given in
following table.
Location
Facia switches are located on the front console.
Sr.
Description
Colour of
Legend
Type
Colour of
No
(Fig. 18)
illumination for
Sticker
ON state
on switch base
1
Dummy
--
--
--
--
2
Switch fuel flap
Amber
Not latched. ON only
Green
(Optional)
when pressed in
3 Switch rear fog lamp
Amber
Latched in ON
Orange
4 Switch rear window
Amber
Position Not latched
heater
ON only when Pressed in
Red
5
HazardWarning
--
Latched in
10 Pole
Switch
On Position
Connector
6
Switch front
Green
Latched in
Orange
On Position
7
Switch rear washer
Green
Not latched
Natural
ON only when
Pressed in
8
Switch rear
Green
Latched in
Black
ON position
9
SW Headlamp
Rotary
Black
levelling
