67

4 DLT ENGINE

F

it oil sump with NEW gasket. Tighten mounting

screws to specified torque. Refer Figure 130

Install -

- Power steering pump mounting bracket.

- A/C Compressor mounting bracket. Refer

Figure 131

- Water pump.

- Oil cooler assembly.

- Oil filter. Refer Figure 132

Install

- Timing gear train rear cover.

- Idler roller.

- Fan mounting bearing block.

- Tensioner roller.

Fig. 131

Fig. 132

Fig. 130
