HVAC
56
10.3.10. CONDENSER
1. Remove the radiator (Refer Radiator removal
process).
2. Loosen and remove the 4 condenser mounting
bolts on the radiator and separate out the con-
denser.
FOR PETROL
FOR DIESEL
! CAUTION
Never leave the condenser lines open immediately
cover them with caps, otherwise the desiccant
which is in-built in the condenser may absorb the
moisture from surrounding air and get contaminat-
ed.
FOR PETROL
FOR DIESEL
