TIAGO

HVAC

Do’s

Don’ts

Risk

Remove blower speed control connector

Do not touch or pull

the wires.

Wire terminal back out

and locked broken if not

handled properly.

Remove the control panel from HVAC unit and put it into

standard control panel bin.

Don’t damage the

control panel.

Scratch mark or damage

mark may appear if not

handled properly.

Mount the control panel in the console and fit the small

wire connector.

Cable can bend if not

handled properly

Fit the blower speed control connector to control panel.

Wire terminal back out

and lock broken if not

handled properly.
