TIAGO

911 / 1002

HVAC
1
10.1 GENERAL INFORMATION
10.1.1 SPECIFICATIONS
Make MAHLE
Refrigerant R -134a
Refrigerant charge quantity (gms)
500±20 gms (for Diesel Version)
600±20 gms (for Petrol Version)
COMPRESSOR (10S11)
Model 10S11
Type Piston
Displacement 116.7 cc
Compressor oil grade ND-8
Compressor Oil Quantity 120 +10 cm3
CONDENSER Petrol Diesel
Type of construction Compact Tube & fin with Integral RD
Max. operating pressure (bar) 31Kgf/cm2 31Kgf/cm2
Type of Desiccant Grace MS-594
Quantity 55 ± 3 gms 41 ± 3 gms
EVAPORATOR
Type Plate & Fin Type
Capacity 9 KW @ 500 m3/hr
HEATER COIL
Type U - Type Aluminum Core
THERMOSTATIC EXPANSION VALVE
Type Block Type Gas Charge
Capacity 2 Tons
Superheat setting 1.7 bar at 00 C and 2.55 bar at 100 C
