9.2.16 REAR OUTER DOOR LOCK
REMOVAL
1. Remove the rear door trim.
(For procedure
refer rear door trim removal process which is
same as that of front door trim removal.
)
2. Remove the plug.
3. Remove the mounting screw of rear door lock.
4. Remove the lock barrel.
5. Slide the gripper handle at back.
6. Remove the gripper handle.
7. Remove the door outer handle screw.
8. Disconnect the links of outer door handle and
lock barrel and remove the outer door handle
bracket from the door shell.
FITMENT
For fitment follow reverse procedure of removal.
