9.2.20 TAIL GATE TRIM
REMOVAL
1. Open the tail gate.
2. Loosen and remove two mounting bolts of
tailgate wiper motor cover.
3. Remove tail gate wiper motor cover.
4. Pry out tailgate trim by plastic wedge / fingers
and pull out trim gently.
NOTE
While pulling out the tail gate trim, care should be
taken such that tree clips do not get damage.
Below image gives location of tree clips on tail
gate trim.
FITMENT
1. Match Tailgate trim buttons properly with the
hole.
2. Press trims gently, ensure its proper fitment.
