RELAY DETAILS:
RELAY NO.
FUNCTION
RATING
R1
---
---
R2
Follow Me Home Relay (MID+, MID)
20A
R2
Signal Inversion Relay (BASE)
20A
R3
Starter Relay 2
20A
R4
EMS ECU - MAIN RELAY
40A
R5
Cooling Fan (SLOW)
20A
R6
Cooling Fan (FAST)
40A
R7
INT Wiper (ON)
20A
R8
AC Clutch Relay
20A
R9
Front Wiper Controller (BASE)
---
R10
HVAC Adaptation Rly
40A
R11
Fuel Pump
20A
R12
Front Fog Lamp (MID)
20A
R13
Head Lamp (Low Beam)
20A
R14
Head Lamp (High Beam)
20A
R15
Front Wash Pump (BASE)
20A
R15
Rear Wiper Relay (HIGH)
20A
R16
Horn Relay
20A
R17
Ignition Relay
40A
R18
Front Wiper Speed
20A
R19
Starter Relay 1
20A
