CLUTCH SENSOR SPECIFICATIONS
1
Principle Of Operation
Hall Effect Based Position Sensing
2
Output Type
Open Collector, Active Low
3
Sensor Type
Non-Contact Type (Hall Effect)
4
No Of Sensing Positions
2
5
Sensing Accuracy At System Level
15%
6
Sensor Supply
14 V Typical
7
Operating Voltage Range
6V TO 18 V
8
Operating Current
25mA MAX
9
Logic High (V
OH
)
(Sensor Supply -1.0V)
10
Logic Low (V
OL
)
<0.6 V MAX
11
Reverse Voltage
Supply & GND
18V MAX, FOR 1 HOUR
Output & GND
18V MAX, FOR 1 HOUR
12
IP Class
IP67
13
Mounting Location
On Clutch Lever, Passenger Compartment
14
Life
10 Lakhs
15
Operating Temp
-30 ºC TO +85 ºC
16
Storage Temp
-40 ºC TO +95 ºC
SIGNAL OUTPUT @CLUTCH POSITION
PEDAL POSITION
PEDAL TRAVEL
OUTPUT
1
<Position 1
< (65±15%)
O/P-1:V OH
O/P-2:V OH
2
Position 1
(65±15%)
O/P-1:V OL
O/P-2:V OH
3
Position 1-2
>65<75
O/P-1:V OL
O/P-2:V OH
4
Position 2
(75 15%)
O/P-1:V OL
O/P-2:V OL
5
Position 2
(>75 Travel)
O/P-1:V OL
O/P-2:V OL
