ELECTRICAL
201
FUSE DETAILS
FUSE NO
FUNCTION
FUSE DESCRIPTION
F1
Interior F/B 2 Ignition
60A
F2
ABS
40A
F3
Glow Plug
60A
F4
Cooling Fan /PWM
40A
F5
EPAS
60A
F6
---
---
F7
Interior F/B 1 Battery
60A
F8
Under bonnet F/R Box
60A
F9
---
---
F10
Ignition Load
60A
F11
---
---
F12
Compressor
10A
F13
Starter Solenoid
20A
F14
ABS ECU
25A
F15
---
---
F16
Horn High/Low Tone
15A
F17
Front Fog
10A
F18
EMS Battery
10A
F19
---
---
F20
Fuel Pump
15A
F21
Brake Lamp
10A
F22
Relay Coils
5A
F23
---
---
F24
Front Wiper Motor
20A
F25
ABS
5A
F26
Washer Motor
10A
F27
---
---
F28
Reverse & Brake Lamp
10A
F29
Rear Wiper
10A
