B2501- 12

Horn Relay - Circuit short to Battery

B1609 - 14

Door Lock Relay - Circuit Short to Ground or Open

B1609 - 12

Door Lock Relay - Circuit Short to Battery

U100F - 11

Ignition Power mode Input - Circuit Short to Ground

U100F - 12

Ignition Power mode Input - Circuit Short to Battery

U1000 - 11

Accessory Power mode Input - Circuit Short to Ground

U1000 - 12

Accessory Power mode Input - Circuit Short to Battery

U1010 - 11

Key In Signal - Circuit Short to Ground

U1010 - 12

Key In Signal - Circuit Short to Battery

U100E - 11

Crank Power mode Input - Circuit Short to Ground

U100E - 12

Crank Power mode Input - Circuit Short to Battery

U100E - 23

Crank Power mode Input – switch stuck low

B1F00 – 11

Accessory Delay Signal – Circuit Short to Ground

B1F09 – 11

Interior Lamp Deactivation Signal – Circuit Short to Ground

U1013 – 11

Wake-Up Signal – Circuit Short to Ground

U1013 – 12

Wake-Up Signal – Circuit Short to Battery

U1014 – 09

Ignition Switch Failure

B221E - 11

Heated Rear Windscreen Relay - circuit short to ground

B221E - 15

Heated Rear Windscreen Relay - circuit short to battery or open

B2238- 11

Rear Defogger switch circuit short to GND/ Open

B2238- 12

Rear Defogger switch circuit short to BATT

B2238- 23

Rear Defogger switch circuit short to GND

U1613 – 64

System Customization Data - signal plausibility failure

U1613 – 64

System Customization Data - signal plausibility failure

B220C - 11

Front Washer Switch - Circuit Short to Ground

B220C - 12

Front Washer Switch - Circuit short to Battery or Open Circuit

B220C – 23

Front Washer Switch – Signal Stuck Low
