TIAGO

ELECTRICAL

REMOVAL& INSTALLATION

REMOVAL

1. Gently pry out the switch bezel from the front

door by pushing the mounting clip with the

screw driver.

2. Remove the switch assembly from bezel.

3. Disconnect the electrical connector & take out

the switch assy.

Same procedures are to be followed for co-drivers

and passengers window module switches

INSTALLATION

1. Connect the electrical connector of switch.

2. Position the switch onto the bezel and push fit

the assembly.

NOTE:

Follow the same procedure to remove

remaining door windowwinding switches.
