ELECTRICAL
77
8.18.6 DTC FOR INFOTAINMENT SYSTEM
Displayed DTC Code DTC Description
B1C01-11
AM/FM Antenna Signal Input Short to GND
B1C01-12
AM/FM Antenna Signal Input Short to Battery
B1C01-13
AM/FM Antenna Signal Input Open Circuit
B1C33-2A
Hard Switch Signal Input – Stuck in Range
B1C0D-12
Microphone Ground- Short to Battery
B1C0E-11
Microphone Signal Input - Short to GND
B1C0E-12
Microphone Signal Input Short to Battery
B1C0E-13
Microphone Signal Input Open Circuit
B1C0A-13
Rear Left speaker-Open circuit
B1C0B-13
Rear Right speaker-Open circuit
B1C08-13
Front Left speaker-Open Circuit
B1C09-13
Front Right speaker-Open Circuit
B1C0A-12
Rear Left speaker-Short to Battery
B1C0B-12
Rear Right speaker-Short to Battery
B1C08-12
Front Left speaker-Short to Battery
B1C09-12
Front Right speaker-Short to Battery
B1C0A-11
Rear Left speaker-Short to GND
B1C0B-11
Rear Right speaker Short to GND
B1C08-11
Front Left speaker-Short to GND
B1C09-11
Front Right speaker-Short to GND
B1C20 – 2A
Steering Wheel control Signal Input – Stuck in Range
B1C20 – 11
Steering Wheel control Signal Input Short to GND
B1C20 – 13
Steering Wheel control Signal Input Open Circuit/Short to Battery
U0028-13
Vehicle Communication Bus A - open circuit
U0028-88
Vehicle Communication Bus A - Bus off
U0155-08
Lost communication with Instrument Panel Cluster Module- Message Time Out
Failure
U0140-08
Lost communication with Body Control Module- Message Timeout Failure
U0159-08
Loss of communication with Park Assist Control Module- Message Timeout
Failure
U0164-08
Loss of communication with HVAC Control Module- Message Timeout Failure
U0423-81
Invalid Data received from Instrument Panel Cluster Module- Invalid serial data
received
U0424-81
Invalid Data received from HVAC Control Module- Invalid serial data received
U045A-81
Invalid Data received from Park Assist Control Module- Invalid serial data
received
