STEERING

23

B. ELECTRICAL TROUBLESHOOTING

Concern

Cause

Remedy

Lack of Support

Steering column failure

1.Read error memory with diagnostic tool.

2.Remedy failure or replace steering

column

3.Read DTC with Diagnostic tool

Cable splice on steering column

vehicle wiring harness defective or

not plugged in correctly

1.Check cable splice / plug in correctly

2. If cable splice damaged, replace

3. vehicle wiring harness or steering

column

4.Read DTC with Diagnostic tool

Vehicle power supply at power

connector insufficient

1.Check vehicle power supply at power

connector between the pins

2.Nominal value: greater than 9 V

3.Check fuse/wiring harness in vehicle or

replace it

4.Read DTC with Diagnostic tool

Vehicle power supply insufficient at

vehicle signal connector

1.Check vehicle power supply between

pins on terminal 15 and ground/earth

2.Nominal value: greater than 9 V

3.Check fuse/wiring harness in vehicle or

replace it

4.Read DTC with Diagnostic tool

Faulty CAN bus signal in vehicle

signal connector

1.Check differential voltage between CANL

and CANH

2.Nominal value: 0.1...1.0 V (value

fluctuates)

3.Check terminating resistor between

CANL and CANH

4.Nominal value: approx. 60

5.Physical check of the CAN bus.

6.Read DTC with Diagnostic tool
