DRIVETRAIN-TA65 Star
37
SR.
NO.
DESCRIPTION
01
SHIFTER SHAFT (5/R SPEED)
02
DOG (5/R SPEED)
03
ASSY DOWEL SLEEVE
04
SHIFTER FORK;5/R SPEED
05
DOG (3/4 SPEED)
06
FINGER;SWING LEVER RI
07
BALL 8 DIA GRADE-20 IS2898
08
SHIFTER SHAFT (3/4 SPEED)
09
SHIFTER FORK 3/4
10
SHIFTER SHAFT (1/2 SPEED)
11
INTERLOCK & SHIFT FINGER ASSY
14
FORK ASSY INTEGRAL (1/2)
17
BELL CRANK LEVER ASSY
18
HEX FL BOLT M8X25 TS17070 8.8
SS8451S2-Y
20
CROSS PIN (SHIFTER / SELECT
FINGER)
21
SPACER (SELECTOR SHIFTER
SHAFT)
22
SHAFT SELECTOR & SHIFTER ASSY
23
OIL SEAL (SELECTOR SHIFTER
SHAFT) M/S SIGMA
SR.
NO.
DESCRIPTION
24
CIRCLIP E 12X1.3 IS3075 PT3 SS8400
25
COVER;TOP
26
SPRING (5TH / REV SELECTION)
27
SPRING (1ST/2ND SELECTION)
28
CUP
29
BUSH (SELECTION)
30
NYLOC NUT M8 IS7002-8-SS8451S2-Y
31
SPACER (BELL CRANK LEVER)
32
SEALING RING (BELL CRANK LEVER)
33
BUSH (SELECTOR SHIFTER SHAFT)
KOEL
35
BRACKET ASSY TOP COVER
37
H/FL BOLT M8X55 TS17130-10.9-
SS8451S2-YH
38
BUSH (SELECTOR SHIFTER SHAFT)
KOEL
39
SPIRAL PIN
40
BREATHER
41
DUST CAP
42
CAP SCREW M6X16 IS2269-12 9
SS9400
43
BELLOW (SELECTOR SHIFTER
SHAFT)
