415 / 1002
DRIVETRAIN-TA65 Star
33
SR.
NO.
DESCRIPTION
1
TRANSAXLE ASSY WITH ABS W/O
VSS
2
HOUSING FRONT HALF
3
HOUSING REAR HALF
4
CYL.PIN (HSG.FRT.HALF TO
HSG.REAR HALF)
5
INPUTSHAFT COVER
6
OIL SEAL (INPUT SHAFT);CR INDIA
6
OIL SEAL (INPUTSHAFT) FENNER
6
"OFFER DRG" OIL SEAL (INPUT
SHAFT)
6
OIL SEAL (INPUT SHAFT) CR
6
OIL SEAL (INPUT SHAFT) (M/S SIGMA
NOK)
7
HEX SCREW M6X10 TS17070-8.8-
SS8451S2-Y
8
ASSY.REVERSE LEVER
9
BARREL REVERSE DETENT
10
BRACKET REV.LEVER
11
PIVOT PIN (REVERSE LEVER)
12
OIL SEAL (DRIVE SHAFT) WITH DUST
LIP;CR
12
"OFFER DRG" OIL SEAL (DRIVE
SHAFT)
12
OIL SEAL(DRIVE SHAFT)WITH DUST
LIP;SIGMAN
13
HEX FL NUT BM8 TS17430 10
SS8451S2-YH
14
HEX FL SCR M8X22 TS17070-8.8-
SS8451S2-Y
SR.
NO.
DESCRIPTION
15
HEX FL BOLT M8
16
BRACKET(CABLE ANCHOR)TA65*
INTEGRATION
17
LINEAR BEARING (INA)
18
CYL PIN 6m6X12 IS 2393
19
HEX FL BOLT M8X38 TS17070-8.8-
SS8451S2-Y
20
BRACKET WIRING HARNESS ON
TRANSMISSION
21
SPRING (REVERSE DETENT)
22
HEX FLANGE SCREW (REAR COVER)
23
ASSY.REAR COVER
24
HEX FL NUT AM6 TS17430-8-
SS8451S2-Y
25
SEALING WASHER 16X22 IS3175 CU
26
MAGNETIC DRAIN PLUG
27
FILLER PLUG
28
SEALING WASHER 8X14 IS3175 CU
30
H/FL BOLT M8X55 TS17070-10.9
SS8451S2-YH
31
OIL CHANNEL
32
HEX FL BOLT M8X38 TS17070-8.8-
SS8451S2-Y
33
SWITCH REVERSE LIGHT
33
REVERSE LIGHT SWITCH
33
REVERSE LAMP SWITCH
33
REVERSE LIGHT SWITCH
33
REVERSE LIGHT SWITCH
