1.05L REVOTORQ ENGINE
145
SPECIAL TOOL
LH Mounting Bracket -:
5424 5890 24 03
3. Fit Elbow with gasket (for EGR Valve) to
cylinder block
4. Assemble EGR Valve with gasket.
5. Assemble Charge Air Pipe with gasket.
6. Install EGR Pipe assembly with gasket.
7. Install Assy. Vacuum Modulator.
