1.05L REVOTORQ ENGINE
151
Pin Details :
Pin
Function Description
6
Low Side Drive Injector 1
7
Injectors High Side Drive
8
Fuel Consumption
9
Battery Ground
10
Swirl / Tachometer / Fuel Pulse /
Coolant Gauge
11
IMV Drive
12
12V Protected Battery Supply
13
Brake Switch
14
Crank Sensor Negative
15
Crank Sensor Positive
16
Sensor Ground Return #1
17
Clutch Switch
18
Can Low (Dev Only)
19
Can High (Dev Only)
20
Sensor Ground Return #2
21
Reserved / Kl50
22
Not Used
23
Not Used
24
Not Used
25
Low Side Drive Injector 2
26
Glow Plug Relay
27
CEL
28
Battery Ground
29
Starter Motor Control
30
Glow Plug Lamp
31
12V Protected Battery Supply
32
AC Demand Switch
33
Vehicle Speed Signal
34
Cam Sensor Signal
35
Diagnostics K-Line
36
Inlet Air Temperature
Pin
Function Description
37
Accelerator Pedal 1
38
Accelerator Pedal 2
39
Spare
40
Rail Pressure Sensor
41
Power Hold Relay
42
Not Used
43
Not Used
44
Low Side Driver Injector 3
45
EGR Drive (EVRV)
46
Water In Fuel Lamp
47
Fan High Speed Drive
48
Ac Clutch Control
49
T15 Key- Switch
50
Security Switch
51
Spare Digital Switch
52
Spare
53
Spare
54
Spare
55
MAF
56
Spare
57
Spare
58
Sensor Ground Return #3
59
Sensor Ground Return #4
60
Not Used
61
Not Used
62
Not Used
63
Low Side Drive Injector 4
64
Spare
65
Spare
66
Fan Low Speed Drive
67
MIL
