1.05L REVOTORQ ENGINE
144
13. Connect the injector back leak tube.
14. Fit HP pipes connected between the common
rail and injectors.
ix.
ON ENGINE SUPPORT STAND :
1. Using Front and Rear lifting hooks, place the
engine on Support Stand.
SPECIAL TOOL
Engine Support Stand -:
5401 5890 24 01
2. Remove the LH and RH engine mounting
bracket.
SPECIAL TOOL
RH Mounting Bracket -:
5401 5890 24 02
