ENGINE INSPECTION SHEET
CAMSHAFT JOURNAL AND BEARING BORE
SHEET 5
Engine No. ………………………………………
Chassis No. …………………………………….
Kilometers ………………………………….......
Kilometers since last overhaul …………………
Reason for dismantling …………………………………..
………………………………………………………………
………………………………………………………………
………………………………………………………………
CAMSHAFT JOURNAL
NO.1
CAMSHAFT JOURNAL
Conclusions/
Recommendations
Checked by…………………..
Date ………………………….
JOURNAL
NO.
Measuring Direction
Remark
Dia. A
mm
Dia. B
mm
Ovality
mm
1
aa
bb
2
aa
bb
3
aa
bb
4
aa
bb
Run-out of intermediate
journals when
supported on journal
Nos. 1 & 4
Camshaft re-ground
to repair size
2
3
4
1
2
3
4
5
CAMSHAFT BEARING BORE
(Bearing Shells installed)
Bearing
No.
Measuring Direction
Remark
Dia. A
mm
Dia. A
mm
Ovality
(mm)
1
2
3
4
