ENGINE
159
ENGINE INSPECTION SHEET
CONNECTING ROD BEARING AND PARENT BORES
SHEET 4
Engine No. ………………………………………
Chassis No. …………………………………….
Kilometers ………………………………….......
Kilometers since last overhaul …………………
Reason for dismantling …………………………………..
………………………………………………………………
………………………………………………………………
………………………………………………………………
Measuring
Direction
BIG END BEARING BORE DIA. (WITH SHELLS INSTALLED) GAUGE SET AT....mm
A (mm)
1
2
3
4
B (mm)
C (mm)
OVALITY (mm)
WEIGHT GROUP SMALL END:
COLOUR MARK BIG END:
Measuring
Direction
CONNECTING ROD BIG END PARENT BORE GAUGE SET AT....mm
A (mm)
1
2
3
4
B (mm)
C (mm)
OVALITY (mm)
CONNECTING ROD BIG END PARENT BORE GAUGE SET AT....mm
1
2
3
4
A (mm)
B (mm)
C (mm)
OVALITY (mm)
ALIGNMENT
1
2
3
4
TWIST
BEND
Conclusions/Recommendations
Checked by …………………..Date …………
