999 / 1428
TRANSAXLE
138
4. Screw the three ‘New Screws M6x15’ for
fixing on ‘Power Unit Base Plate’ body at the
right torque 10 ± 1 Nm.
NOTE
Oil top up must be done only when
diagnostic tool is available. In case of an
emergency, remove the vehicle connector
and leave for half an hour. If oil level is
below minimum level top up oil to the mid of
‘Min and Max’.
Don’t reuse the AMT oil once it is drained.
5. Fill the ‘Oil Tank’ with new ‘CS Speed’ oil, at
the Max. Level of quantity 0.50 liter@ no
pressure in the hydraulic circuit and restore it
after the purge procedure.
6. Screw the ‘Oil Tank Cap’ at the right torque 2
± 0.5/1 Nm.
