TRANSAXLE (NANO AMT)
78
E. TOP COVER ASSEMBLY:
SL NO DESCRIPTIONS
SL NO DESCRIPTIONS
01
B MOUNT BRACKET
09
INTERLOCK ASSY (AMT)
02
STUD
10
SPIRAL PIN (6X28)
03
CAP SCREW M10X35
11
CIRCLIP E 12X1.3
04
TOP COVER SUB ASSEMBLY HOUSING
12
SUB ASSY INHIBITOR
05
STUD M8X35
13
INHIBITOR LOCK SCREW
06
SELECTOR SHIFTER SHAFT
14
SELECTION SPRING
07
INHIBITOR FIXED DOG (TOP COVER)
15
INTERFACE FINGER
08
SPIRAL PIN
