ENGINE COMPONENTS

22

6.0 OIL FILTER REMOVAL AND RE-

FITMENT PROCEDURES ON VEHICLE:-

Removal:

1. Open the tail gate.

2. Pull the both side strip simultaneously

(located behind the rear seat) to fold the seat.

3. Open the parcel tray.

4. Disconnect the speaker wiring harness

connector.

5. Pull out the parcel tray from both side from

guide bush simultaneously.
