HVAC
BLOWER RESISTOR
Removal
1. Disconnect the electrical connector of blower re-
sistor.
2. Remove the blower resistor mounting screw.
Installation :
1. Tighten the screw and install blower resistor.
2. Connect the electrical connector.
2. Turn blower unit (anticlockwise) to unlock from the
housing and take out the blower unit.
Installation
1. Install blower unit into the housing and turn (clock-
wise) to lock.
2. Tighten the blower unit screw.
BLOWER UNIT
Removal
1. Disconnect the electrical connector of blower unit
and remove the screw securing blower unit to the
HVAC unit.
3. Take out the blower resistor.
