631 / 1428
ELECTRICAL
619
ELECTRICAL
17) Remove the Bearing Collar from the Rotor
assembly.
18) Remove and Separate the DE Bracket assy. from
the Stator winding assembly.
19) Remove and Separate the Spacer from theArma-
ture assembly.
20) Remove and Separate the DE Fan from the Ro-
tor assembly.
16) Remove the Pulley from the DE Bracket assy.
21) Remove the rivet from the DE Bracket assembly.
