ELECTRICAL
609
ELECTRICAL
Note:
Pull out ONLY Connector and not the wire.
3. Remove terminal 30 (battery + ve) from the alternator.
4. Loosen lower mounting bolt of alternator.
5. For ease of service, to access upper mounting bolt
of the alternator, remove rear shelf and tail gate. For
removal & refitment of rear shelf and tail gate refer
body section.
6. Loosen upper bolt of the alternator i.e. alternator
belt-tension adjusting bolt.
7. Disconnnect the AC compressor belt and then
remove the alternator belt from the damper pulley.
8. Remove the belt from alternator pulley.
NOTE: Check the condition of belt. Replace if wear
down or any cut is found.
