1050 / 1980
TRANSAXLE (NANO AMT)
106
4. Install the rear half oil channel, by matching
the protrusion on the casing as well as on the oil
channel.
13. FRONT HALF HOUSING:
A. DISMANTLING:
1. Remove the dowel pins (02 No’s) and remove
the oil collector by unscrewing the bolt.
2. Remove the input shaft oil seal.
3. Remove the clutch stopper assembly Refer
the Clutch Stopper assembly procedure.
4. Remove the lay shaft bearing outer race.
5. Take out the oil collector.
