TRANSAXLE-AMT
43
Installation:
NOTE
Ensure AMT kit engage piston slot is at center
(Neutral) and transaxle is in neutral prior to
assembling.
1. Before proceeding to install ‘AMT KIT’, remove
the old sealant thoroughly and clean the
assembly by air.
2. Clean ‘AMT KIT’ base mounting plate by air
and apply the fresh sealant properly (Silicon
liquid gasket three bond 12S001 or ANABOND
690).
3. Ensure that interface finger is in neutral
position (this can be done by pushing the
selector shifter shaft vertically downwards. If it
moves it is in neutral. Otherwise rotate it to
bring it in neutral). Bring the slot of engage
piston of the ‘AMT KIT’ approximately at the
center (it will be in the same line as selection
piston center). Assemble the ‘AMT KIT’
carefully by using the studs on the ‘AMT’ top
cover for alignment.
4. Tighten the all three M8x45 bolts and two M8
nuts by ratchet and extension socket (12 mm)
as per specified torque. (21~24.5 Nm).
