NANO

366

DRIVETRAIN

5. Unscrew the four top cover M8 bolts (01) and

remove the top cover (02).

TRANSAXLE DISMANTLING

1. Remove all electrical connections i.e., Reverse

lamp and Vehicle speed sensor connectors.

2. Remove the clutch actuator lever assembly, for

procedure refer, ‘CLUTCH ACTUATION

MECHANISM OVERHAUL’.

3. Unscrew and remove the 2 bolts on the front half

housing.

4. Unscrew and remove the 3 M10 bolts on the ‘B’

mount bracket.

7. Unscrew the bolts (01) and remove the cable

anchoring bracket (02)..

6. Remove the interlock pins from the housing
