NANO

1234 / 1904

ENGINE
7
5. REMOVAL AND REFITMENT OF ENGINE
ACCESS WINDOW AND ENGINE COVER
A. ENGINE ACCESS WINDOW
Removal:
NOTE:
 Park the vehicle with brakes ON and duel
selector switch is kept in CNG mode.
 Manually turn of the tank valve and connect
the TML tester tool and start the service
“Empty CNG lines”
 Crank the engine and run in idle condition
until engine stop at its own.
 Re crank the engine it should not start (tank
pressure should be 0 bar)
WARNING :
 Do not turn OFF Cylinder Valves , in vehicle
running in CNG mode. This may wrongly
detect the leakage error.
 Pull the strip which is located left side behind the
upper part of rear seat.
 Fold the upper part of rear seat
 Remove the mounting bolt of upper rear seat to
body.
 Remove the two mounting bolts located bottom
of lower rear seat.
