BRAKES

42

REMOVAL

1. Pry out the lower cover of steering column.

(For procedure refer Body section).

2. Remove hush panel from driver side

(1)

by

removing mounting screws.

3. Remove upper nacelle and lower nacelle.

(For

procedure refer Body section).

4. Disconnect the brake pedal return spring from

steering column mounting bracket and

remove the same from the brake pedal.

5. Remove the Steering column assembly from

intermediate shaft end.

(For removal

procedure refer Steering section).

6. Remove clutch master cylinder assembly.

(For procedure refer Clutch section).

7. Disconnect electrical connection of brake light

switch.
