BRAKES
30
Follow the same procedure of draining for other
three calipers in the sequence given below:
•
Front caliper
(RHS)
•
Rear caliper
(LHS)
•
Rear caliper
(RHS)
F. BRAKE LIGHT SWITCH ADJUSTMENT
1. Place the brake pedal in release position.
2. Loosen the lock nut
(3).
3. Adjust the brake switch
(1)
till the gap between
the brake switch
(1)
and the switch stopper
(2)
on the brake pedal is 2mm. For details refer
figure given below:
4. After confirming gap tighten the lock nut.
