ENGINE
133
5. Loosen & remove EMS wiring harness mounting
screw
.
6. Remove HP pipes connected between the com-
mon rail and injectors.
NOTE
•
After opening the HP pipes cover the opening
with suitable caps.
•
Do not reuse the HP pipes once removed, use
new at the time of assembly.
7. Loosen & remove nut
(1)
of fuel pressure line
from common rail and the bolt
(2)
for removing
the bracket holding the pipe.
8. Loosen the nut (1) of fuel pressure line from HP
pump and remove the fuel pressure line.
