ENGINE
131
FUEL LEVEL SENSOR
The Fuel level sensor assembly consists of float and
a sensor. Fuel level sensor assembly provides the
signal to indicate the fuel level in the tank. As the
float arm assembly moves with respect to the fuel
level in tank, resistance at sensor harness varies
accordingly.
ROLL OVER VALVE
The ROV is integrated with Tank unit. The ROV al-
lows only the flow of fuel vapour and does not allow
liquid fuel to flow from the vent line.
.
In case of a vehicle roll-over, the venting system is
closed by the Roll-Over Valve which avoids any fuel
leakage.
