HVAC
59
10.3.8 PRESSURE SWITCH
REMOVAL
1. Discharge the refrigerant using standard recover-
ing equipment.
2. Disconnect electrical connector.
3. Loosen and remove pressure switch.
For dual A/C unit
For single A/C unit
FITMENT
For fitment follow reverse procedure of removal.
10.3.9 CONDENSER
REMOVAL
1. Discharge the refrigerant.
2. Remove front bumper assembly
(For procedure
refer front bumper removal procedure in body
section).
3. Disconnect the refrigerant lines
.
4. Loosen and remove the 4 mounting bolts and
separate the assembly from vehicle.
! CAUTION
Close the open ports with suitable cap.
FITMENT
For fitment follow reverse procedure of removal
