ENGINE 1.3 QUADRAJET (75PS)
2. The specified resistance values and calibration details of the Suction unit fuel gauge are given below :
44 liters tank
Parameters
Float positions
FULL
3//4
HALF
1//4
EMPTY HIGHT
EMPTY LOW
Resistance value in OHMS
8
34
58
89
100
120
Tolarance in OHMS
±2
±2
±2
±2
±2
±2
Height in MM
163
127
91
47
32.2
8
Volume (LTRS) (USABLE)
(42±1)
(32±1)
(22±1)
(10.7±1)
(7±1)
(1.5±1)
