ENGINE 1.3 QUADRAJET (75PS)
73
Fig. 156
B. INTANK FUEL PUMP (TANK UNIT):
The electric fuel pump is assembled in a single unit
with the level gauge.
1. Fuel return connector
2. Fuel supply connector
3. Electrical connection
4. Electric fuel pump
5. Fuel level sensor
3
1
2
4
5
