ENGINE 1.3 QUADRAJET (75PS)
18
NOTE
Make sure that the Engine and Transaxle
assembly is free from all other wiring and hoses
before proceeding to loosen the mounts.
17. Fix the chain to the lifting points (If using a
chain hook with two end then fix it to points
(1) & (2)) and raise the lift till the chains are
just in tension.
18. Remove the C mount by removing the bolt.
19. Now lift the chain hook to slightly lift the
engine and remove the bolt of the B mount
through the hole provided in the battery tray.
20. Free the engine off the A mounts by loosening
and removing the bolts.
21. Now slightly lower the engine and move it
forward.
NOTE
When moving the engine forward pay close
attention to any wire or hose which might not have
been disconnected from the Engine Transaxle
Assembly.
