ENGINE 1.3 QUADRAJET (75PS)
13
B. ENGINE OIL FILTER CARTRIDGE
REPLACEMENT.
1. Unscrew the two Torx (T-30) screws and the
hexagonal nut of the oil filter cover and remove
the oil filter cover.
2. Remove the oil filter housing by unscrewing it by
placing a suitable box spanner on the hexagonal
protrusion on top of it.
3. Since the oil filter cartridge is snapped to the
housing it will also come along with the oil filter
housing.
4. Hold the oil filter housing firmly and pull out the
cartridge by giving a slight anti clockwise rotation.
NOTE
Before replacing the oil filter cartridge, wipe clean the
old oil from inside of the oil filter housing and smear
some fresh engine oil to it.
5. While replacing the oil filter cartridge, snap the
new cartridge into the oil filter housing.
6.
Place the oil filter housing along with the oil filter
cartridge properly and hand tighten the same and
then tighten it to a torque of 25 N-m using box
spanner.
7. Install the oil filter cover and tighten the two Torx
screws and the hexagonal nut.
