ZEST AND BOLT - page 227

ENGINE 1.3 QUADRAJET (75PS)
2
SR. NO. DESCRIPTION PAGE NO.
3A.1.3 ENGINE COOLING 60
A. SYSTEMDESCRIPTION 60
B. COMPONENTS 61
3A.1.4 LUBRICATING SYSTEM 62
A. COMPONENTS 62
B. CONTRUCTION &WORKING 62
3A.1.5 FUEL SUPPLY SYSTEM 63
3A.1.5.1 INTRODUCTION 63
3A.1.5.2 COMPONENTS 64
3A.1.5.2.
1
VACUUMPUMP 64
3A.1.5.2.
2
INJECTORS 64
A. IMACLASSIFICATION 65
3A.1.5.2.
3
SINGLE FUEL MANIFOLD PIPE 66
3A.1.5.2.
4
FUEL FEED SYSTEM 67
A. FUEL TANK 69
B. IN TANK FUEL PUMP 73
C.FUEL LEVEL SENSOR 74
D. FUEL LEVEL GUAGE 78
E. FUEL LEVELWARNING UNIT 81
F. FUEL FILTER 81
G. FUEL FILLER CAP 82
H. FUEL HOSESAND LINES 82
I. ASSEMBLY FILLER NECK COMPLETE 83
3A.1.6 INTAKE SYSTEM 84
A. WORKING 84
3A.1.7 EXHAUST SYSTEM 85
A. DESCRIPTION 85
B. COMPONENTS 85
C. EXHAUST GAS RECIRCULATION (EGR) 86
D. EGR SOLENOID VALVE 87
E. EXHAUST PIPE REMOVAL 88
3A.1.8 ENGINE MANAGEMENT SYSTEM 89
3A.1.8.1 SYSTEM OVERVIEW 89
3A.1.8.2 FUNCTIONAL DESCRIPTION 89
