Revotron 1.2T
170
Sr. No DTC CODES
DTC DESCRIPTION
75
P0691 A/C Fan 1 Control Circuit Low
76
P0692 A/C Fan 1 Control Circuit High
77
P0217 Engine Coolant temperature over 110 deg C
78
P3001 Engine Stall due to Overheating, Coolant temperature over 120 deg C
79
P0351 Max error (SCB) in IGBT Channel A with faulty system voltage
80
P0352 Max error (SCB) in IGBT Channel B with faulty system voltage
81
P2187 System Too Lean at Idle
82
P2188 System Too Rich at Idle
83
P2279 Intake air system leak
84
P0222 Throttle/Pedal Position Sensor/Switch "B" Circuit Low
85
P0223 Throttle/Pedal Position Sensor/Switch "B" Circuit High
86
P2135
7KURWWOH 3HGDO 3RVLWLRQ 6HQVRU 6ZLWFK ³$ %´ &LUFXLW 5DQJH 3HUIRUPDQFH
87
P0121 Throttle/Pedal Position Sensor/Switc
K ³$´ &LUFXLW 5DQJH 3HUIRUPDQFH
88
P2229 Barometric Pressure Circuit High
89
P2228 Barometric Pressure Circuit Low
90
P0035 Turbocharger/Supercharger Bypass Valve Control Circuit High
91
P0034 Turbocharger/Supercharger Bypass Valve Control Circuit Low
92
P0033 Turbocharger/Supercharger Bypass Valve Control Circuit
93
P2103 Throttle Actuator Control Motor Circuit High
94
P2102 Throttle Actuator Control Motor Circuit Low
95
P2101 Throttle Actuator Control Motor Circuit Range/Performance
96
P2100 Throttle Actuator Control Motor Circuit/Open
97
P101A Throttle Actuator Valve Spring
98
P3007 Throttle Actuator Control Motor Circuit Range/Performance
99
P3008 Throttle Actuator Control Throttle Body Range/Performance
100
P2101
Throttle Actuator Control Motor Circuit Range/Performance, Indicates that the
DLR lies outside of the valid control range
101
P2176 Throttle Actuator Control System
±
Idle Position Not Learned
102
P0340
&DPVKDIW 3RVLWLRQ 6HQVRU ³$´ &LUFXLW
103
P0504
%UDNH 6ZLWFK ³$´ ´%´ &RUUHODWLRQ
104
P0243
7XUERFKDUJHU 6XSHUFKDUJHU :DVWHJDWH 6ROHQRLG ³$´
105
P0245
7XUERFKDUJHU 6XSHUFKDUJHU :DVWHJDWH 6ROHQRLG ³$´ /RZ
106
P0246 Turb
RFKDUJHU 6XSHUFKDUJHU :DVWHJDWH 6ROHQRLG ³$´ +LJK
107
P0234 Turbocharger/Supercharger Overboost condition
108
P0299 Turbocharger/Supercharger Underboost condition
109
P060B ECM/PCM Processor
110
P0605 Control Module Performance
111
P060D
Internal Control Module Accelerator Pedal Position Performance
